Beware of low quality so called foldable/expandable look alike homes that are made with much lighter weight steel, low quality windows and doors,
no gable roof structures and very thin sandwich panels that are advertised on USA platforms. Our homes weigh thousands of pounds more.
Some are coping our pictures and videos. This site is copyrighted - trademarked protected and is locked.
Illusion Homes uses Q355 Steel which is commonly used in structural engineering projects, including high-rise buildings, bridges, and heavy machinery.
Illusion Homes are the only factory-built steel super structure premium homes in the world that can withstand a Cat 5 Hurricane.
See structural/wind tests below that will withstand a minium wind speed of 165.5333 MPH or more when welded to a concrete foundation or pylons.
5 - year craftsmanship warranty 25 - year structural warranty
OUR SUPERIOR STRENGTH IN OUR HOMES OF STEEL Q355 IS IN THE CHEMICAL MAKE UP
Illusion Homes uses Q355 Steel which is commonly used in structural engineering projects,
including high-rise buildings, bridges, and heavy machinery.
Q355 Steel: Properties, Grades, Equivalent ASTM Material and More
This thorough overview explains the qualities, grades, and similar ASTM materials of Q355 steel. Understand the strength, weldability, and formability of Q355 steel, which makes it appropriate for a variety of structural applications. Learn about the various types and grades of Q355 steel, including Q355B, and their unique features. Find the closest ASTM material equivalent to Q355 steel and learn about its mechanical qualities and applications. Whether you work in construction, engineering, or manufacturing, this guide will help you make informed decisions about Q355 steel for your next project.
Some steel grades that are equivalent to Q355 steel
The equivalent grades of Q355 steel vary depending on the international standards being used for comparison. Here are some commonly used equivalents:
ASTM A572 Gr 50: This is an equivalent grade to Q355 in the American ASTM standards. It has a minimum yield strength of 345 MPa and is commonly used in structural applications.
S355JR: This is an equivalent grade to Q355 in the European EN standards. It has a minimum yield strength of 355 MPa and is widely used in structural and engineering applications.
SM490B or SM490C: These are equivalent grades to Q355 in the Japanese JIS standards. They have minimum yield strengths of 325 MPa and 365 MPa, respectively, and are commonly used in structural applications.
Grade of Q355 steel (mác thép q355)
Q355 steel is a high-strength structural steel grade that is commonly used in various industries and applications. However, it’s important to note that there isn’t a specific “grade” of Q355 steel as it is not classified using traditional grade designations like Q235 or Q345. Instead, Q355 is typically categorized based on its chemical composition and mechanical properties.
Different variations or types of Q355 steel exist, such as Q355B, Q355C, Q355D, and Q355E, each with its own specific composition and properties. These variations are distinguished by factors like carbon content, additional alloying elements, and specific heat treatment processes.
The Q355B equivalent ASTM material
The equivalent ASTM material for Q355B steel is ASTM A572 Grade 50. ASTM A572 Grade 50 is a structural steel with high strength and low alloy content that is widely utilized in structural applications. Both Q355B and ASTM A572 Grade 50 have a minimum yield strength of 355 MPa (50 ksi) and possess similar mechanical properties.
ASTM A572 Grade 50 offers excellent weldability and formability, making it suitable for a wide range of structural applications, including bridges, buildings, and machinery. It has a higher strength-to-weight ratio compared to many other steel grades, providing superior load-bearing capacity
When comparing equivalencies between steel standards, keep in mind that chemical composition and mechanical qualities may vary slightly. When selecting a comparable ASTM material for Q355B steel, it is recommended that you examine the applicable specifications and standards or seek expert assistance for accurate information.
Q345 vs Q355: What is the difference?
Q345 and Q355 are both high-strength low-alloy (HSLA) structural steels commonly used in various industries and applications. While they share some similarities, there are also key differences between Q345 and Q355. Here is a comparison of the two grades:
Chemical Composition
Mechanical Properties
Impact Toughness
Applications and Usage
Videos 3 and 4 are testing our Illusion Homes insulation and sandwich panels with Acetylene & Oxy-Acetylenes torch.
Acetylene burns at a temperature of 2,200°C or 4,000°F, and when combined with an oxygen tank to produce oxy-acetylene can reach temperatures as high as 3,300°C or 6,000°F, making it the hottest commonly available gas used for cutting steel.
